Progressive distributors MX-F are built in a variable
disk construction. Therefore the distributor can be,
depending on the number of lubrication points,
extended or shortened. Because of the disk
construction there is the possibility to join individual
distributor disks (middle element, end element) with
different metering volumes together to one complete
progressive distributor.

SSV are single block progressive metering devices that reliably divide the incoming lubricant in predetermined individual quantities. SSVs can be used with high backpressures, and they are ideally suitable for a wide range of temperatures. The maximum operating pressure is 350 bar. SSV metering devices are available with 6 to 22 outlets. Monitoring is possible via pin indicator for visual system monitoring or with piston detector for electrical system monitoring.
